Thermal Cycler

Thermal cyclers from Gallenkamp offer proven performance and unmatched features. Perfect for any laboratory, whether you run only a few samples per week or perform high-throughput processes.

Category:
Register to download brochure
WHERE TO BUY
GO BACK

    Product

    Sku

    Name (required)

    Country (required)

    Company

    Email (required)

    Message

    In PCR, precise and accurate block control is paramount. Gallenkamp’s thermal cyclers have six independently controlled thermal electric modules, the heating and cooling elements of the thermal cycler to maintain tight temperature uniformity at all points during a run-even during ramping.

    • Flexible and interchangeable sample blocks
    • Intuitive touch screen
    • Specially designed lids reduce evaporation during PCR
    • Low energy consumption
    • Simple data transfer
    • Interchangeable blocks
    • 3 independent blocks version T960 model

    Ordering Information

    Code  Description  Dimensions WxHxD mm  Weight (kg)
    T960-3  T960 three block touch screen PCR thermal cycler  380x270x250mm  8.1
    T960-CT  T960 gradient touch screen PCR thermal cycler  380x270x250mm  8.1
    B960-CB  B960 gradient colour display PCR thermal cycler  380x270x250mm  7.8
    K960-CK  K960 PCR thermal cycler  380x270x250mm  7.2
    K960-CKF  KF960 PCR thermal cycler  380x270x250mm  7.2



    Specifications

      T960  B960  K960  KF960
    Block formats  96×0.2ml  54×0.5ml  96×0.2ml

    77×0.5ml

    386 well
    Temp Range 0C  00C-99.90C  00C-99.90C  00C-99.90C  40C-99.90C
    Interface  7” LCD  5.7” LCD  5.7” LCD  5.7” LCD
    Max Heating Ramp rate  50C/s  4. 50C/s  4.00C/s  4.00C/s
    Max cooling Ramp rate  50C/s  4.00C/s  3.50C/s  3.50C/s
    Hot lid temp 0C  20-1100C  20-1100C  30-1150C  30-1150C
    Memory capacity  2000  1000  200  200
    Max Ncycles  999  999  99  99
