Thermal cyclers from Gallenkamp offer proven performance and unmatched features. Perfect for any laboratory, whether you run only a few samples per week or perform high-throughput processes.
Thermal Cycler
In PCR, precise and accurate block control is paramount. Gallenkamp’s thermal cyclers have six independently controlled thermal electric modules, the heating and cooling elements of the thermal cycler to maintain tight temperature uniformity at all points during a run-even during ramping.
- Flexible and interchangeable sample blocks
- Intuitive touch screen
- Specially designed lids reduce evaporation during PCR
- Low energy consumption
- Simple data transfer
- Interchangeable blocks
- 3 independent blocks version T960 model
Ordering Information
| Code | Description | Dimensions WxHxD mm | Weight (kg) |
| T960-3 | T960 three block touch screen PCR thermal cycler | 380x270x250mm | 8.1 |
| T960-CT | T960 gradient touch screen PCR thermal cycler | 380x270x250mm | 8.1 |
| B960-CB | B960 gradient colour display PCR thermal cycler | 380x270x250mm | 7.8 |
| K960-CK | K960 PCR thermal cycler | 380x270x250mm | 7.2 |
| K960-CKF | KF960 PCR thermal cycler | 380x270x250mm | 7.2 |
Specifications
| T960 | B960 | K960 | KF960 | |
| Block formats | 96×0.2ml | 54×0.5ml | 96×0.2ml
77×0.5ml |
386 well |
| Temp Range 0C | 00C-99.90C | 00C-99.90C | 00C-99.90C | 40C-99.90C |
| Interface | 7” LCD | 5.7” LCD | 5.7” LCD | 5.7” LCD |
| Max Heating Ramp rate | 50C/s | 4. 50C/s | 4.00C/s | 4.00C/s |
| Max cooling Ramp rate | 50C/s | 4.00C/s | 3.50C/s | 3.50C/s |
| Hot lid temp 0C | 20-1100C | 20-1100C | 30-1150C | 30-1150C |
| Memory capacity | 2000 | 1000 | 200 | 200 |
| Max N0 cycles | 999 | 999 | 99 | 99 |
