    This Koch Steam Steriliser electrically heats water and steam produced disinfects, small unwrapped instruments and other non-porous equipment

    Featuring double skinned walled chamber for insulation purposes with removable shelves for ease of loading.The lid is designed to ensure condensed steam runs back into the chamber. Lifting handles on both the unit and lid which features an 18mm diameter thermometer/thermocouple entry port.

    For water level control the Koch Steriliser has a filling port and water level indication in an external reservoir. Connect laboratory tubing to filling port and a water supply, adjust the water flow to gently top up the water level, to maintaining boiling.

    This unit is not intended for sterilisation of equipment used in clinical care of patients.

    Product Information

    Product Code  Dimensions Capacity Temp Range Shelf size 1st Shelf  2nd Shelf  Heater Power (220-240V) Voltage Packed Weight
    KS1 External: 329w 329d x 690h mm


    Internal: 300w x 302d x 500h mm


    Packed: 43 x 43 x 57cm

    		 Nominal Tank Capacity: 35 litres Provides constant boiling water producing steam. 288 x 288mm 190mm Working height on shelf with second shelf fitted. 202mm Working height on shelf two with the gable lid fitted. Additional height for taller vessels can be obtained in the centre of the shelf. 1000W 230V 17 kg
    KS2 External: 431w x 431d x 690h mm


    Internal: 400w x 400d x 500h mm


    Packed: 610 x 540 x 551mm

    		 Nominal Tank Capacity: 60 litres Provides constant boiling water producing steam. 390 x 390mm 189mmWorking height on shelf with second shelf fitted. 205mmWorking height on shelf two with the gable lid fitted. Additional height for taller vessels can be obtained in the centre of the shelf. 1000W 230V 25.5kg
    KS3  External: 500w x 800d x 600h mm


    Internal: 470w x 770d x 580h mm

    Packed: 800w x 1200d x 800h mm

    		 180 litres Provides constant boiling water producing steam. 480mm Working height on shelf with lid fitted 2000W 230V 63 kg

    Safety Features

    Safety Features

    Always connect the filling port in the external trough with laboratory tubing to a water supply, adjust the flow to gently top up the water level, whilst maintaining boiling.

    The unit is protected by a thermal cut out which is manually reset.

    Always read the instruction book.
